1. The machine adopts the imported arc synchronous wheel drive double transmission, stable operation and easy maintenance.
2. The machine adopts the Delta frenquency converter, Schneider, electronic components, operation humanity, the machine run more stable ,saving of the power.
3. The machine converter adopts double ivory adjustment, convenient and accurate.
4. The belts adopt multiple widen, thicken imported belts, ensuring the continuous paper delivery, automatic paper feeding, accurate paper folding.
5. It is equipped with the automatic amending device, making sure the accurate folding, gluing quality stable.
6. Pressing department adopt imported wider belts, conveying smooth.
7. Adopting the Human-Machine Interface and the PLC operation system, equipped with the photoelectric counting.
8. It is equiped with the automatic orderliness device, the skewed products will be revised automatically during the folding process, ensure the products great.
9. Pressing Department adopt the PVC belts, according to the pressure adjustment ,equipped with the sponge belts, ensure the quality of the hook bottom products, sticky firmly.
10. The machine is suitable for the cardboard and E, C, B, A corrugated box, and the three layers of paper gluing box.
11. The machine can produce the general paste , four edges hook bottom patching ,the configuration of the four hexagonal box and the different shaped box can be choosed.

Model	LZHX-1100AC
Sheet Thickness	Cardboard, E/B/C corrugated
Max. Speed	200m/min
Total Power	21KW
Overall Dimensions	13500×1800×1500mm
Weight	7.5T

Modle	LZHX-1380AC
Sheet Thickness	Cardboard, E/B/C corrugated
Max. Speed	200m/min
Total Power	21KW
Overall Dimensions	14600×2100×1500mm
Weight	8.5T

Model	LZHX-1450C
Sheet Thickness	cardboard, E/B/C/A corrugated
Max. Speed	200m/min
Total Power	25KW
Overall Dimensions	14600×2300×1500mm
Weight	10.5T

Model	LZHX-1600C
Sheet Thickness	A/B/E/C corrugated
Max. Speed	200m/min
Total Power	30KW
Overall Dimensions	16000×2400×1500mm
Weight	13.5T
