1. Double servo drive, high precision, reduce mechanical transmission, lower failure rate.
2. Automatic baffle, easy operation and save time.
Touch screen operation, change parameters(nail distance, nail number, nail type, rear baffle) fast and conveniently.
3. Changing size just needs 1 minute.
4. Count automatically on feeding unit, delivery automatically after the bundles, facilitate to bundle.
5. Can be used for stitching lid box and no cover box.
6. Equipped with automatic alarm device after nail line used up.
7. From semi-finished products to finished products, just need two workers, operate easily, reduce wages.

Model	LZDX-2000
Max(L+W)×2	2460mm
Min(L+W)×2	606mm
Max(H+C)×2	1515mm
Max(H+C)×2	300mm
Hight of Feeder	900mm
Stitching Pitch	30-120mm
Power	6Hp
Length	4500mm
Width	2100mm
Weight	2000kg
Speed	450 staples
Number of Stitching	1-99 stitches
