Main Characteristics
A.Suitable for corrugated board A, B, C, AB, three, five-layers cardboard.
B.Reduce manpower dependence, replace manual gluing and nailing operation.
C.Gluing evenly and do not glue out, easy to dry and clean.
D.The effect of nailing is better, nailing distance is more accurate, the appearance is more beautiful.
E.The glued cartons have the features of firm, smooth and clean.
F.Nail spacing: 40-500mm.
G.Nailing speed: 1050 nailing/min
H.The output of paper folding, deviation correction, nailing, gluing and counting stacking can be completed automatically.
I.Servo control board correction and nailing.
J.Nailing angle: 45 °.
K.Single and double nails can be adjusted freely, applicable to national standards 17 and 18.
L.Less manpower, fast speed, 2 people for paper feeding, 2 people for bundling, 2 people for back and forth transport, 8 hours reach more than 100,000 pieces easily.
M.Suitable for export packaging, environmental protection packaging,such as beverage box, beer box, instant noodle box, ceramic tile box and other high-level packaging boxes.

Main Specifications

Max sheet: 900x2600	Total fixed current:25A
Min Sheet: 300x850	Power supply: three-phase four-wire distribution (three-phase 380V+ 0+ ground wire)
Delivery Speed: 0-130m/min	Overall Size(Length x width x height): 16500 x 3000 x1800mm
Total Power:21.1kw	Net Weight: 10t
