Electrical Control system adopted computer control which can keep paper's feeding, transferring, die cutting and delivery in automatic control and real-time detection.Man-machine interface indicating system will show machine's working state, trouble's position and its solution.There are various safe guarding devices that when accident occurs, it will give an alarm by sound and light and shut-down automatically to protect safety of man and machine.

Model	LZ-1500P
Max. Die-cutting Speed	4500 sheets/h
Die-cutting Precision	±0.25mm
Max. Die-cutting Pressure	300T
Max. Paper Size	1500×1100mm
Min. Paper Size	550×450mm
Max. Die-cutting Size	1490×1090mm
Corrugated pape	≤8mm(max. thickness)
Total Power	22KW
Weight	20T
Dimensions	8400×2600×2500mm

Model	LZ-1060P
Max. Die-cutting Speed	7500 sheets/h
Die-cutting Precision	±0.1mm
Max. Die-cutting Pressure	250T
Max. Paper Size	1060×760mm
Min. Paper Size	450×360mm
Max. Die-cutting Size	1050×750mm
Cardboard	80-2000g/m²
Corrugated pape	≤5mm (max. thickness)
Total Power	18KW
Weight	16T
Dimensions	5950×2100×2300mm
