1. Suction Nozzle Unit:
Non-stop suction nozzle paper feeding ,ensured the paper not damaged,and
driving adopts mechanical transmission,stable performance.
2. Paper Transferring Unit:
Yaskawa servo motor and Japan's Mitsubishi controller are adopted,
moving setting ensure no damage to the front edge of paper when paper touching
the front lay.
3. Die-cutting Unit:
High Precision flat die cutting platform with worm,worm rod.
Multi-Layer intermittent driving system,overload protection torque clutch.
High precision Renold gripper bar chain
4. Paper Delivery Unit:
Automatic paper platform,non-stop belt paper delivery system
5. Electrical Unit:
PLC system and troubleshooting system ensurc stable running with safe and
easy.
6. Stripping Unit:
Center Positioning fast stripping plate locking system,top stripping frame
loading and fasten system.Three frames stripping unit.The stripping plate
is made from hard alloy aluminum.Great designed stripping
needle can be fastened easily.



Model	LZ-1320-QP
Max.Paper Size	1320×960mm
Max.Paper Size	450×420mm
Max.Die-cutting Size	1300×940mm
Max.Die-cutting Pressure	300N/cm²
Paper Processed Carbord Corrugated Paper	200-2000/m² 1-8mm
Max.Die-cutting Speed	5500S/H
Msx.Feeding Pile Height	1600mm
Max.Delivery Pile Height	1500mm
Total Power	26KW
Dimensions	11000×4600×2750
Machine Weight	23.5T

Model	LZ-1520-QP
Max.Paper Size	1520×1100mm
Max.Paper Size	1500×1080mm
Max.Die-cutting Size	1300×940mm
Max.Die-cutting Pressure	300N/cm²
Paper Processed Carbord Corrugated Paper	250-2000/m² 1-8mm
Max.Die-cutting Speed	5500S/H
Msx.Feeding Pile Height	1700mm
Max.Delivery Pile Height	1600mm
Total Power	30KW
Dimensions	12000×4810×2750
Machine Weight	25T

Model	LZ-1700-QP
Max.Paper Size	1700×1200mm
Max.Paper Size	1680×1180mm
Max.Die-cutting Size	1300×940mm
Max.Die-cutting Pressure	300N/cm²
Paper Processed Carbord Corrugated Paper	300-2000/m² 2-9mm
Max.Die-cutting Speed	5500S/H
Msx.Feeding Pile Height	1700mm
Max.Delivery Pile Height	1600mm
Total Power	35KW
Dimensions	12000×4850×2750
Machine Weight	34T
